Description

Part Number DMB1-12A is a two-port mixer utilizing bridge diode quad. RF and IF are diplexed into the same port via an internal diplexer. At crossover frequency (RF = IF), response for each is down 3 dB. Self-adjusting biasing automatically reduces dc bias level as the LO power is increased. Available with options such as built-in PIN limiter on the RF port. Contact factory.

Part Number DMB2-18A is a one-port design utilizing a bridge quad of Schottky diodes. RF and IF are directed into separate ports via an internal diplexer. The LO port uses a self-adjusting biasing circuit which automatically decreases the dc voltage as the LO power is increased.

Environmental
