CSD87350Q5D 87350D

Description:

The CSD87350Q5D NexFET™ power block is an optimized design for synchronous buck applications offering high-current, high-efficiency, and highfrequency capability in a small 5-mm × 6-mm outline. Optimized for 5-V gate drive applications, this product offers a flexible solution capable of offering a highdensity power supply when paired with any 5-V gate drive from an external controller or driver.

Specifications:

• Half-Bridge Power Block
• 90% system Efficiency at 25 A
• Up to 40-A Operation
• High-Frequency Operation (Up to 1.5 MHz)
• High-Density SON 5-mm × 6-mm Footprint
• Optimized for 5-V Gate Drive
• Low-Switching Losses • Ultra-Low-Inductance Package
• RoHS Compliant
• Halogen Free
• Lead-Free Terminal Plating

Datasheet:

http://www.ti.com/lit/ds/symlink/csd87350q5d.pdf
