RT6575A RT6575B 6575A 3G= 3F= QFN-20

Type

Brand new RT6575A RT6575B  3G= 3F QFN-20

The RT6575A/B is a dual-channel step-down controller generating supply voltages for battery-powered systems. It includes two Pulse-Width Modulation (PWM) controllers adjustable from 2V to 5.5V, and two fixed 5V/3.3V linear regulators. Each linear regulator provides up to 100mA output current and 3.3V linear regulator provides 1% accuracy under 35mA. The RT6575A/B has an oscillator output to drive the external charge pump application. Other features include on-board power-up sequencing, a powergood output, internal soft-start, and soft-discharge output that prevents negative voltage during shutdown

Features:

  • Support Connected Standby Mode for Ultrabook
  • CCRCOT Control with 100ns Load Step Response
  • PWM Maximum Duty Ratio > 98%
  • 5V to 25V Input Voltage Range
  • 2V to 5.5V Output Voltage Range
  • 5V/3.3V LDOs with 100mA Output Current
  • 1% Accuracy on 3.3V LDO Output
  • Oscillator Driving Output for Charge Pump Application
  • Internal Frequency Setting
  • 300kHz/355kHz (CH1/CH2)
  • Internal Soft-Start and Soft-Discharge
  • 4700ppm/°C RDS(ON) Current Sensing
  • Independent Switcher Enable Control
  • Built-in OVP/UVP/OCP/OTP
  • Non-Latch UVLO  Power Good Indicator
  • RoHS Compliant and Halogen Free

Datasheet:

https://goo.gl/L8Nfg7
